Performance characteristics
The keyhole is flat and porous, the center distance is adjustable, dual motors, variable speed drill set, pneumatic positioning, convenient and fast.
The side shape of the keyhole adopts milling cutter swing device, motor frequency conversion, and special positioning device to realize semi-automatic milling and shaping.
Technical parameter
| Max.milling depth | 120mm |
| Max.milling length | 220mm |
| Max.milling width | 30mm |
| Working rising and falling height | 100mm |
| Main spindle speed | 10000转/分（rpm） |
| Power | 1.1/2.2/1.1/1.1kw |
